Overview

It takes serious patience and superior optics to locate trophy animals at extreme distances. The Kaibab HD delivers the premium-quality, high-magnification optical performance you need to get the job done. Intended to be used with a tripod for extended, comfortable, rock-steady viewing.

Note - Recommended for use with a tripod. Tripod adapter included.

In the Box

  • Rainguard
  • Lens cloth
  • Tethered objective lens covers
  • Comfort neck strap
  • Deluxe padded carry case
  • Uni-Daptor quick-release tripod adapter

Features

  • APO System: Index-matched lenses correct color across the entire visual spectrum.
  • HD Lens Elements: Premium extra-low dispersion glass delivers the ultimate in resolution and color fidelity, resulting in high-definition images.
  • XR™ Plus Fully Multi-Coated: Ultimate anti-reflective coatings on all air-to-glass surfaces provide maximum light transmission for peak clarity and the pinnacle of low-light performance.
  • Dielectric Coating: Multi-layer prism coatings provide bright, clear, color-accurate images.
  • Plasma Tech: Cutting edge coating application process provides unparalleled coating durability and performance
  • Phase Correction: Coating on roof prism models enhances resolution and contrast.
  • Roof Prism: Valued for greater durability and a more compact size.
  • Waterproof: O-ring seals prevent moisture, dust and debris from penetrating the binocular for reliable performance in all environments.
  • Fogproof: Argon gas purging prevents internal fogging over a wide range of temperatures.
  • ArmorTek ®: Ultra-hard, scratch-resistant coating protects exterior lenses from scratches, oil and dirt.
  • Rubber Armor: Provides a secure, non-slip grip, and durable external protection.
  • 56 mm Lenses: Maximize low light performance.
  • Adjustable Eyecups: Twist up and down for comfortable viewing with or without eyeglasses.
  • Center Focus Wheel: Adjusts the focus of both binocular barrels at the same time.
  • Diopter: Adjusts for differences in a user's eyes. Located on right eyepiece.
  • Tripod Adaptable: Compatible with a tripod adapter, allowing use on a tripod or car window mount.

Specifications

BrandVortex
Model #KAI-5618
Objective Lens Diameter56mm
Magnification18x
Prism StyleRoof Prism
Objective Size56-59mm
Exit Pupil3.1
Eye Relief16.4
Shortest Focusing Distance6.04
Interpupillary Distance60 - 76
Length (mm)196
Weight (grams)1220
Field of View (Linear)64.7m @ 1000m
Field of View (Degrees)3.7

Warranty

OUR VORTEX INTERNATIONAL VIP WARRANTY IS ABOUT YOU, NOT US.

The Vortex Worldwide Lifetime VIP Warranty covers your purchase worldwide through the distributor or dealer in the country where you purchased your product. In Australia this is Extravision Australia.

Distributors and dealers in countries other than where you made your purchase may apply service charges due to different rules and regulations in that country. We recommend you make your purchases from your local distributor or dealer to ensure you get the best service should there ever be a need.

Products shipped from the USA out of the country are considered Gray Market Products and are not covered by this warranty.


The VIP Warranty does not cover loss, theft, deliberate damage or cosmetic damage that does not hinder the performance of the product.
