Overview

Specialist scopes designed by airgunners for airgunners!

Airmax scopes feature our H2 optics in a variety of configurations designed to suit airgun characteristics.

  • Capped Low-Profile Turrets
  • 1 Inch Mono-tube chassis
  • Wide Angle
  • 16 layer Fully Multi-Coated lenses
  • High torque zoom ring
  • Fast focus eyebell
  • AMX reticle designed for airguns

Nitrogen purged. Shockproof. Waterproof. Fog proof.

All calibre rated.

Hawke Warranty.

AMX Reticle

Both the AMX and AMX IR glass etched reticles are based on the spacing of a 10x Mil Dot. The AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.

Half Mil Dot spacing on the lower post provides increased aim points for long shots.

The horizontal bars are calculated at 0.5, 1.5, 2.5, 3.5 and 4.5 mil spacing. Hollow posts are segmented into mil spacing and can be used for bracketing.



In the Box

  • Instruction Manual

  • Lens Cloth

  • Lens Covers

Specifications

BrandHawke Optics
Model #13140
Magnification RangeMedium (11x-18x)
Exit Pupil12.5 - 4.2
Field of View (Degrees)5.7 - 2.1
Field of View (Linear)10 - 3.7m @ 100m
Weight (grams)620
Length (mm)329
Parallax Distance9m to Infinity
Windage Travel70 MOA
Elevation Travel70 MOA
Windage Turret StyleCapped
Elevation Turret StyleCapped
Adjustment Graduation.25 MOA
Eye Relief90
Tube Size1"/25.4mm
Illuminated ReticleNo
Objective Size50-55mm
Magnification4-12x
Turret StyleCapped
AdjustmentMOA
Parallax AdjustmentAdjustable Objective
Objective Lens Diameter50mm
ReticleAMX
Focal PlaneSFP (Second Focal Plane)
