HikMicro RAPTOR series is a powerful and innovative handheld thermal and digital night vision binocular which adopts a 12 μm infrared thermal sensor with NETD < 20 mK sensitivity, 2560 × 1440 low illumination optical sensor with built-in adjustable IR illuminator, and a precise built-in laser rangefinder up to 1000 m measuring distance. It offers excellent image quality in true living color or thermal during day and night observation in adverse weather conditions with up to 2600 m detection range. The binocular is mainly applied for day & night observation, hunting, hiking, searching and rescuing.

The HikMicro Raptor Pro RQ50 binoculars combine industry-leading thermal performance with a high-performance day and night vision camera to deliver the ultimate detection capability in an ergonomic and easy to use package

The detail of the thermal image you see on the screen is defined by the quality of the components and their ability to measure small differences in temperature. The RAPTOR is equipped with HikMicro’s all new SUB 20 NETD 640x512px sensor, this is the most accurate available on the market today. Another first is the F0.9 aperture 50mm lens system which offers an unrivalled ability to transmit the thermal signal, ensuring that more of the detail reaches the sensor. These key components combine to deliver highly detailed thermal images and the best performance in adverse weather conditions.

The HikMicro Raptor thermal has an integrated 1000m laser range finder system that outputs the distance within the viewing screen, so there is no need for second guessing or estimating range, the LRF allows for precision measurement day or night.

The Raptor also has a high-quality day & night optical camera built in. During daylight hours you can call on a detailed full-colour image to help identify the heat source you have located. When it gets dark the camera switches to night mode and the inbuilt IR will help you to see up to 400m in the dark. The inbuilt image stabilisation reduces handshake and allows you to use the Raptor like a conventional set of binoculars and get a clear image even at high magnification.

The final lens on the front of the Raptor belongs to the Integrated Laser Range Finder. This can measure distances of targets up to 1000m away and is accurate to ±1m. The Raptor also has a compass and GPS built in for detailed location information.

The ergonomic chassis is comfortable for use over a long period and allows all of the major controls to fall easily to hand. The focus for the thermal image is located on the bridge of the binoculars, between the eyepieces while each button falls comfortably to a finger and is intuitive to use, even in the dark. The Raptor is powered by 3x 18650 batteries to give a run time of 8 hours and the detachable battery compartment makes it easy to change.

The dual eyepieces deliver information to both eyes at the same time which aids detection and is more comfortable for use over a long period. The Raptor can be adjusted to comfortably fit your eyes with the interpupillary distance being adjusted from 60mm to 70mm giving you an excellent view of the HD OLED display. The inbuilt sensor can tell when you take the binoculars away from your face and automatically switches the displays off to eliminate any light spill that may illuminate you in the dark.

The All-In-One Solution

In combination with thermal camera, digital day & night camera, and laser rangefinder, the ultimate innovative RAPTOR series binocular provides unprecedented observation capability in thermal or true living color, up close or from a distance, during day or night in adverse weather to break through your visual limitation.

20mK High Sensitivity Thermal Camera

Extremely high thermal sensitivity, NETD<20mK | High Definition Thermal Sensor, 384x288 @12μm | Super large aperture f/0.9 lens, 19% improvement | Image Pro, enhanced self-developed image processing algorithm | Long detection range up to 2600m with a standard 1.7m tall object | Powerful magnification up to 91x, up to 5.7x optical magnification in combination with 16x digital zoom.

2560x1440 HD Day & Night Camera

High resolution image2560x1440, delivering bright and vivid image at daytime | Support low light conditions 0.001Lux. With built-in 850nm IR illuminator, the image is still visible clearly under complete darkness. | The unique defog mode ensures the image clarity during foggy day.

1000m Laser Rangefinder

Built-in laser rangefinder with a range of up to 1000m with an accuracy of ± 1 meter helps get the target distance to make the right decisions.

Purpose-Built Intelligent Features

Automatic Display On & Off

When moving the device temporarily from your eyes, the display will be turned off automatically. There will be no light leakage from the eyepiece of the device.


The GPS and Digital Magnetic Compass(DMC) feature ensures to locate the objects exact position through the precise measurement of an accurate azimuth relative to the direction of the magnetic north pole and a precise elevation of the observed object relative to the observer .

Smart IR

With the different conditions of observation, the IR illuminator can adjust brightness automatically and intelligently to avoid overexposure. In such way, it also can reduce the power consumption and improve battery life.

Local Album

The recorded photo and video can be browsed in local album of the device for more convenient and quick viewing.

Groundbreaking and Pratical Design

Designed by the Red Dot award-winning designer

The RAPTOR series, designed by the Red Dot award-winning designer team, not only meet the real needs of users, but also allow users to experience the aesthetic beauty of technology.

Intuitive Operation

The interpupilary distance of RAPTOR is adjustable from 60mm to 70mm to satisfy different users’ demands, and also it supports the diopter range from -5 D to +3 D. The intelligent button arrangement is perfect for the intuitive operation.

More advantages

Model # RH50L
Brand HikMicro
Objective Lens Diameter 50mm
Field of View 9.3mx 7.0m @ 100m
Angular Field of View 5.3 x 4.0°
Sensor Size 384px
Pixel Pitch 12 μm
NETD <20 mK
Maximum Detection Range 2600m
Display Size 1024x768
Optical Magnification 5.7x
Battery 18650
Length 217mm
Weight 1120 grams
