Overview

Specialist scopes designed by airgunners for airgunners!

Airmax scopes feature our H2 optics in a variety of configurations designed to suit airgun characteristics.

  • Capped Target Turrets
  • 30mm Mono-tube chassis
  • Wide Angle
  • Side Focus
  • Illumination
  • 16 layer Fully Multi-Coated lenses
  • High torque zoom ring
  • Fast focus eyebell
  • AMX reticle designed for airguns

Nitrogen purged. Shockproof. Waterproof. Fog proof.

All calibre rated.

Hawke Warranty.

AMX Reticle

Both the AMX and AMX IR glass etched reticles are based on the spacing of a 10x Mil Dot. The AMX offers multiple aim points, useful when shooting air guns with loopy trajectories.

Half Mil Dot spacing on the lower post provides increased aim points for long shots.

The horizontal bars are calculated at 0.5, 1.5, 2.5, 3.5 and 4.5 mil spacing. Hollow posts are segmented into mil spacing and can be used for bracketing.

In the Box

  • Instruction Manual

  • Reticle Booklet

  • Lens Cloth

  • 4" Sunshade

  • Metal Flip-Up Lens Covers

  • Flip-Up Removal Tool

  • 4" Sidewheel

  • Hex Key

  • CR2032 Battery

Specifications

BrandHawke Optics
Model #13311
Magnification RangeMedium (11x-18x)
Exit Pupil12.5 - 3.1
Field of View (Degrees)5.9 - 1.5
Field of View (Linear)10.2 - 2.6m @ 100m
Weight (grams)760
Length (mm)348
Parallax Distance9m to Infinity
Windage Travel27 MRAD
Elevation Travel27 MRAD
Windage Turret StyleCapped Target
Elevation Turret StyleCapped Target
Adjustment Graduation.1 MRAD
Eye Relief102
Tube Size30mm
Illuminated ReticleYes
Objective Size50-55mm
Magnification4-16x
Turret StyleCapped Target
AdjustmentMRAD
Parallax AdjustmentSide Focus
Objective Lens Diameter50mm
ReticleAMX
Focal PlaneSFP (Second Focal Plane)
